【Compatible Model】Hyundai Sonata 2011 2012 2013 2014 with 2.0L / 2.4L Engine; Hyundai Sonata 11 12 13 14 with 2.0L 2.4L Engine;Kia Sorento 2011-2015 ; Kia Optima 2011-2015 ; Kia Sportage 2011-2016
【OE Replace Number】 Hyundai 35320-2G740 35320-2G720
【Installation Step of High Pressure Pump 】 1.Detect high pressure pump O-ring and use clean engine oll slightly wetting insert roller tappet into vacuum pump. 2. Rotate the crankshaft until the roller tappet is at its lowest point Insert the high pressure pump into the vacuum pump.
【Installation Step of High Pressure Pump 】3. Cross tighten the fastening bolt by hand, and cross tighten the fastening bolt with the specified torque of 20N.m. 4. Use engine oil to infiltrate the ball head of the high pressure hose and install it Tighten the lock nut of the fuel distributor indicated by the arrow in the drawing with awrench.
【Installation Step of High Pressure Pump 】5. Fasten the high pressure pipe connector with a wrench and tighten the live joint nut of the high pressure tube with another wrench. 6. Install high pressure pipe clamps and use 5N.m torque to tighten clamps. Start the engine after installation to observe whether there isoil leakage on each interface.
【Package List】 Mechanical Fuel Pump*1
【High Quality】100% Strict Quality Inspection, 100% High Pressure Fuel Pump is Tested before Out of Factory..
【Compatible Model】Hyundai Sonata 2011 2012 2013 2014 with 2.0L / 2.4L Engine; Hyundai Sonata 11 12 13 14 with 2.0L 2.4L Engine;Kia Sorento 2011-2015 ; Kia Optima 2011-2015 ; Kia Sportage 2011-2016
【OE Replace Number】 Hyundai 35320-2G740 35320-2G720
【Installation Step of High Pressure Pump 】 1.Detect high pressure pump O-ring and use clean engine oll slightly wetting insert roller tappet into vacuum pump. 2. Rotate the crankshaft until the roller tappet is at its lowest point Insert the high pressure pump into the vacuum pump.
【Installation Step of High Pressure Pump 】3. Cross tighten the fastening bolt by hand, and cross tighten the fastening bolt with the specified torque of 20N.m. 4. Use engine oil to infiltrate the ball head of the high pressure hose and install it Tighten the lock nut of the fuel distributor indicated by the arrow in the drawing with awrench.
【Installation Step of High Pressure Pump 】5. Fasten the high pressure pipe connector with a wrench and tighten the live joint nut of the high pressure tube with another wrench. 6. Install high pressure pipe clamps and use 5N.m torque to tighten clamps. Start the engine after installation to observe whether there isoil leakage on each interface.
【Package List】 Mechanical Fuel Pump*1
【High Quality】100% Strict Quality Inspection, 100% High Pressure Fuel Pump is Tested before Out of Factory..
